The Style CGI is for use with flat face and raised face flanges, this gasket features increased compressive force for blow-out prevention and is specified for high pressure/temperature service or where corrosive or toxic media are present.
20mm PN100 Spiral Round Gasket - CS 316L Outer / FLEXICARB 316 InnerPRODUCT CODE - PN100-20mm
£2.09Ex. VAT£2.51Incl. VAT
View other size optionsProduct Description
| Approval | BAM for Oxygen, TA Luft |
| Flange Face | Flat, Raised |
| Maximum Temperature | 450°C / 842°F |
| Media | Hazardous |
| Minimum Temperature | -240°C / -400°F |
| Pressure | 431 Bars / 6251.14 PSI |
| Pressure Class | 150, 300, 600, 1500, 2500, 400, 900 |
| Pressure Rating PN | PN10 PN16, PN25, PN40, PN64, PN100, PN160, PN250 |
