Fox K9 Series Pressure Switches - With ATEX Version

Product description

Fox K9 Series Pressure Switches

K5 Series adjustable pressure switches activate a microswitch once the preset value is reached. The pressure is set by rotating a graduated knob as seen in the picture. This system is supplied with a device that locks the pressure setting knob once the desired value is set. Mechanical stops protect both the spring and the microswitch from over pressurisation.

技术功能：

Body:32 mm hexagonal in zinc-plated carbon steel
Metal Ring:Ø 40 mm in anodised aluminim
Assembly:in every position
Working temperature:from -20°C to +80°C
Switching frequency:120 cycles/min
Operating point:adjustable through an external metal ring
Switching accuracy:E.O.S至20°C的±2％
Fixed Hysteresis:~ 15% of E.o.S to 20°C
Weight:0.4kg
机械生活：106 Cycles at 70 bar (1000 psi) at 20°C

Electrical Features
Maximum load:

5安培250伏交流
125伏DC时0.25安培

ATEX versions of this pressure switch are not a standard stock item and are on a long delivery service, pleasecontact usto confirm delivery times before ordering.
